What do the letters on the mixing console mean?

1. Scene Memory - Scene Memory Key, used for editing, storing, and retrieving scenes.

2. Digital I/O - data input and output keys used to set the connection structure and clock frequency of the word synchronous clock.

3. Setup - Set key, used to incentivize solo listening and define system operation priorities.

4. Utility - Multi function key, check the oscillator settings, battery, and channel status.

5. Auto Mix - an automatic mixing key used to stimulate tuning automation.

6. Group - grouping key, used to input channel push sub grouping and mute grouping.

7. MIDI - Electronic Music Digital Interface, used for setting up MiDi channels and functions.

8. Pair - pairing key, used for stereo pairing of input channels. Additional information: Types of mixing consoles: According to different usage purposes and occasions, mixing consoles are divided into the following categories:

(1) Stereo Field Production Console

(2) Recording Console

(3) Music Console

(4) Digital Routing Mixing Console

(5) Powered Mixer

(6) On Air Console

7) Theatre Console

(8) PA Console (9) Wired Broadcast Mixer (10) Compact Mixer Reference: Baidu Baike Mixing Console

2. How to set up the digital panel meter nha-shunt-a-r3nnThe specific settings of the digital panel meter nha-shunt-a-r3nn need to refer to the official manual, but can be operated according to the general process of the digital display meter. The operation process is as follows:

1. After entering the settings interface and powering on, long press the "Settings" button on the device for about 2 s

econds, and the screen will display the settings menu.

. Some models may require pressing other function keys (such as the "confirm" key) or entering an initial password (such as "0000") at the same time, depending on the device prompt. If the operation is ineffective, it is necessary to first consult the instruction manual to confirm the entry method.

2. Parameter Setting Options Overvoltage/Undervoltage Values: Use the directional keys to select the "Voltage Alarm Threshold" option and set the upper limit (overvoltage) and lower limit (undervoltage).

. For example, if a 220V system needs to be monitored, an overvoltage of 242V (10% margin) and an undervoltage of 198V can be set, and an audible and visual alarm can be triggered when the range is exceeded. Select the "current alarm threshold" for overcurrent value and set it according to the specifications of the external shunt. For example, if the shunt is "FL 100" (100A/75mV), the overcurrent value can be set to 100A, and a warning will be triggered when exceeded. The direction of energy accumulation can be selected based on actual needs, either "forward accumulation" (only counting forward power) or "absolute value accumulation" (counting total power, including reverse). The alarm output mode can be selected as "pulse signal" (short triggering), "continuous signal" (alarm continues until the fault is resolved), or "latch release" (requires manual reset). For example, when remote monitoring is required, pulse signals can be used in conjunction with counters. Input the model or specification of the external shunt (such as "FL 050" corresponding to 50A/75mV) to ensure the accuracy of current measurement. If the specifications of the splitter do not match, it
