1. How to read sensor

The pronunciation of sensor is in English; Sensor; Sensitive component reference example sentence 1 He began thinking about how to combine an infrared sensor with a water valve. So he began to think about how to combine infrared sensors with underwater sensors. 2. Motor connections to the tilt sensor to adjust the level state of laser level devices. The motor is electrically connected to the tilt sensor to adjust the horizontal state of the laser level device. dry. If you want to buy a dryer, look for one with an induction device that automatically shuts off the power after the clothes are dried.

2. What can be used instead of a water flow switch (medium is water, water flow and stop, need to output a switch signal because of water flow...

Use a better water flow detection switch, Karman vortex street, glass rotor type, if only detecting flow and stop, micro motion type can also be used.

3. What is a flow switch and what is its working principle? Thank you

Water flow switch is a sensor device used for water circulation control, inlet and outlet control, water heating control, water pump switch control, solenoid valve on/off control or outlet power-off, outlet power on control and other processes in electric water heaters, solar water heaters, air conditioners and other water systems. When a certain flow rate is reached, the water flow is converted into a switch type electrical signal. Construction of water flow switch: The flow switch consists of a magnetic core, a reset spring, a forged copper or carbon shell, and a sensor. The shell is made of H58 forged copper or polycarbonate, the magnetic core is made of neodymium iron boron permanent magnet materi

al, and the sensor magnetic switch is an imported medium power component. The inlet and outlet interfaces are both G1/2 "standard pipe threads. Working principle: When the water flow rate in the pipeline is greater than 0.75L/min, the magnetic core is displaced by the water flow and drives the magnetic source to produce a magnetic control effect, causing the sensor to output a "1" switch signal. This signal is input to the equipment control system, and after power amplification, it achieves the purpose of water flow control. When the water flow rate in the pipeline is less than 0.75L/min, the magnetic core drives the magnetic source back to its original position under the thrust of the reset spring, causing the sensor to output a "0" switch signal and stop the systems operation. Product features: Flow switches have advantages such as high sensitivity and strong durability. Main technical parameters Appearance dimensions: Length X diameter=62mm X Φ 22mm Suitable ambient temperature ≥ 1 ℃ Suitable working temperature ≤ 100 ℃ Minimum starting flow ≥ 0.75L/min Maximum passing flow ≤ 5L/min Rated working pressure ≤ 0.65Mpa Shell maximum pressure ≤ 1.5Mpa Signal output load DC24V/1A, AC36V/1A or AC220V/0.1A Suitable range and conditions

(1) Environmental temperature not lower than 0 ℃. Do not strike the shell. Stay away from magnetic objects.

(2) The output of the signal is a switch quantity, so the connection method of the controlled object must also be a switch control relationship.

(3) The power of the controlled object shall not exceed the signal load capacity.

(4) This device is a water-based control device and cannot be used for controlling other media. Multiple specifications and sizes are use
