Home Peak Flow Meter Asthma Action Plans: Setting Red, Yellow, and Green Expiratory Limits
Quick Answer: This article shows how the red, yellow, and green zone concept from home peak flow meters applies to industrial flow meters. You can use the same three zone logic for alarm settings on Coriolis, electromagnetic, and oval gear meters. Set each zone based on process flow rate, temperature, pressure, and batch volume. This method prevents shutdowns and protects pumps.
Here is the thing. A home peak flow meter helps patients track asthma with red, yellow, and green zones. Industrial flow meters do a similar job for process control. Most engineers skip the simple alarm setup and then face unexpected downtime. We have seen this on customer sites many times.
Why Red, Yellow, and Green Limits Matter in Flow Metering
Flow meters do more than measure. They can trigger alarms when flow moves outside a safe range. A green zone means normal operation. A yellow zone warns you to check the process. A red zone shuts down a pump or opens a bypass. This logic is common in oil and gas, water treatment, chemical dosing, and food beverage plants.
Many users ask for a Coriolis mass flow meter with digital output for alarm limits. Silver Instruments supplies these meters with 4-20 mA HART and pulse outputs. You can wire the alarm output to a PLC or a siren. No complex programming is needed.
Setting the Green Zone for Normal Flow
The green zone covers your standard operating range. For a diesel flow meter on a generator line, the green zone may be 50 to 200 liters per hour. For a thermal mass flow meter on biogas, the green zone may be 2 to 12 cubic meters per hour. For a Coriolis meter on a paint line, the green zone may be 3 to 18 kg/h.
You set the green zone inside the flow meter software or through a paperless recorder. Silver Instruments offers paperless recorders with 8 or 12 channels. You can log flow rate, temperature, pressure, and totalizer data in the green zone. This log helps you prove batch quality later.
Yellow Zone Alerts for Early Warning
A yellow zone triggers when flow drifts above or below normal. For example, a wastewater plant in Vietnam runs an electromagnetic flow meter on a sludge line. Their normal flow is 15 to 25 m³/h. They set the yellow zone at 12 m³/h and 28 m³/h. When the meter reads outside this band, the PLC sends a text alert to the shift engineer.
Yellow alarms should not stop production immediately. They give operators time to check filters, valves, or pump wear. Most engineers skip this part. They jump straight to red limits. That causes nuisance trips. We recommend a yellow zone delay of 5 to 30 seconds depending on the loop response.
Red Zone Shutdown and Safety Thresholds
The red zone is the critical limit. Set this zone for safety, pump protection, or product quality. On a Coriolis mass flow meter dosing catalyst in a chemical reactor, the red zone may be below 0.5 kg/h or above 25 kg/h. At these values the meter sends a relay output to
In the oil and gas sector, a vortex flow meter on a flare line may have a red zone above 2000 standard cubic meters per hour. That signal triggers an emergency alarm on the DCS. Always test the red zone with a dry contact relay check before startup.
Real Application Examples from Customer Sites
A food and beverage plant in Thailand uses a Silver Instruments oval gear flow meter for glucose syrup. The green zone is 200 to 800 liters per hour. The yellow zone starts at 150 liters per hour. The red zone is below 100 liters per hour. That low flow alarm prevents the pump from running dry and stops product waste.
In the Middle East, a desalination plant uses a 12 inch electromagnetic flow meter for seawater intake. The green zone is 500 to 800 m³/h. The yellow zone covers 450 to 900 m³/h. The red zone is below 400 m³/h or above 1000 m³/h. This setup protects the membranes from high shear.
Recommended Silver Instruments Models for Zone Alarms
You need a flow meter with relay outputs or a 4-20 mA signal for alarm zones. Here are the models we often supply for zone based control.
For low flow chemical dosing, use the SIL-CMF-015 Coriolis mass flow meter. It covers 0.5 to 50 kg/h with an accuracy of ±0.2 percent. It has ATEX Zone 1 certification for solvent and catalyst lines. For water and wastewater lines, use the SIL-EMF-050 electromagnetic flow meter. It works with conductivity as low as 5 µS/cm and sizes from DN15 to DN300. For diesel and oil batch transfer, use the SIL-OG-020 oval gear flow meter. It handles 0.3 to 15 cP viscosity and pressures up to 40 bar.
All these meters can send a relay output for yellow and red zones. You can also use a paperless recorder with alarm relays if you need data logging plus control.
FAQ
What is the difference between a yellow zone and a red zone alarm?
A yellow zone warning tells operators to inspect the loop without stopping production. A red zone alarm triggers an immediate shutdown or bypass action.
Can I set different flow limits for two products on the same meter?
Yes. Most Silver Instruments flow meters store multiple configuration files. You can switch zones based on product density, viscosity, or batch recipe.
Which output signal is best for zone alarms?
Use a 4-20 mA HART signal for continuous monitoring and a relay output for hard wired alarms. Some users prefer Modbus RTU for PLC integration.
Do you supply flow meters with ATEX certification for red zone gas alarms?
Yes. Our vortex and thermal mass flow meters have ATEX Zone 1 and Zone 2 options for gas flow measurement.
How do I get a quote with recommended zone settings?
Send us your pressure in bar, temperature in °C, pipe size in DN, and flow range. Our engineers will reply with a meter model and alarm setup table. Tel: +86-25-68650347. Whatsapp: +86-25-52155837. WeChat: +86 15365082610.
